AUTOMATIC CONTROL UNIT, OMD800
AUTOMATIC CONTROL UNIT, OMD800
Register Address R/W Values
REG_RATED_FREQUENCY 625 R/W 1 = 50 Hz
2 = 60 Hz
REG_SECONDARY_LOAD 626 R/W 0 = Not Used
1 = Opening Only
2 = Opening And Closing
3 = Opening Pulse
4 = Opening/Closing Pulse
REG_GENERATOR_USAGE 627 R/W 0 = No Generator
1 = Generator In Use
REG_LINE_PRIORITY 628 R/W 0 = No Priority
1 = Line I - Switch 1
2 = Line II - Switch 2
REG_LANGUAGE 629 R/W 0 = English
1 = German
2 = French
3 = Italian
4 = Spanish
5 = Finnish
6 = Russian
7 = Chinese
REG_PASSWORD 630 R/W 0000...9999
REG_EXT_VT_PRESENT 631 R/W 0 = Absent
1 = Present
REG_EXT_VT_PRIMARY 632 R/W 0 = 100/57 V
1 = 115/66 V
2 = 120/70 V
3 = 208/120 V
4 = 220/127 V
5 = 230/132 V
6 = 240/138 V
7 = 277/160 V
8 = 347/200 V
9 = 380/220 V
10 = 400/230 V
11 = 415/240 V
12 = 440/254 V
13 = 480/277 V
14 = 500/288 V
15 = 550/317 V
16 = 600/347 V
17 = 660/380 V
18 = 690/400 V
19 = 910/525 V
20 = 950/550 V
21 = 1000/577 V
22 = 1150/660 V
