20 2TLC172011M0205_B
Value for yy and zz is given from table below depending on additional data area xx.
Additional Data Area
xx
Node id (0-31)
yy
IO-type (0-255)
zz
00 1E 1F
01 20 21
02 22 23
03 24 25
04 26 27
05 28 29
06 2A 2B
07 2C 2D
08 2E 2F
09 30 31
10 32 33
11 34 35
12 36 37
13 38 39
14 3A 3B
15 3C 3D
16 3E 3F
17 40 41
18 42 43
19 44 45
20 46 47
21 48 49
22 4A 4B
23 4C 4D
24 4E 4F
25 50 51
26 52 53
27 54 55
28 56 57
29 58 59
30 5A 5B
31 5C 5D
5.13 Path description
This chapter only briefly will describe the cryptically path description “6,20 64 24 00 30 14,C6,1”,
6,20 64 24 00 30 14 The path according to the EDS file.
For more information read DeviceNet specification.
C6 The value type code.
For more information read DeviceNet specification.
1 The ending value is the size of the data.
Connected to the value type code in some way.
