ABB Pluto Series User Manual

38 2TLC172011M0205_B
7.2 Output IO configuration
Below is template output IO configuration for the package area 0 – 3 used to send data to the Pluto
system.
Data is structured in bits and grouped into registers. Each package will hold registers
doPackageX_bit for the 16 bit information; doPackageX_reg0 and doPackageX_reg1 for 16 bits
register value.
7.2.1 Package area 0
#
EIO_SIGNAL:
-Name "doPackage0_0" -SignalType "DO" -Unit "ioPluto" -UnitMap "0"
-Name "doPackage0_1" -SignalType "DO" -Unit "ioPluto" -UnitMap "1"
-Name "doPackage0_2" -SignalType "DO" -Unit "ioPluto" -UnitMap "2"
-Name "doPackage0_3" -SignalType "DO" -Unit "ioPluto" -UnitMap "3"
-Name "doPackage0_4" -SignalType "DO" -Unit "ioPluto" -UnitMap "4"
-Name "doPackage0_5" -SignalType "DO" -Unit "ioPluto" -UnitMap "5"
-Name "doPackage0_6" -SignalType "DO" -Unit "ioPluto" -UnitMap "6"
-Name "doPackage0_7" -SignalType "DO" -Unit "ioPluto" -UnitMap "7"
-Name "doPackage0_8" -SignalType "DO" -Unit "ioPluto" -UnitMap "8"
-Name "doPackage0_9" -SignalType "DO" -Unit "ioPluto" -UnitMap "9"
-Name "doPackage0_10" -SignalType "DO" -Unit "ioPluto" -UnitMap "10"
-Name "doPackage0_11" -SignalType "DO" -Unit "ioPluto" -UnitMap "11"
-Name "doPackage0_12" -SignalType "DO" -Unit "ioPluto" -UnitMap "12"
-Name "doPackage0_13" -SignalType "DO" -Unit "ioPluto" -UnitMap "13"
-Name "doPackage0_14" -SignalType "DO" -Unit "ioPluto" -UnitMap "14"
-Name "doPackage0_15" -SignalType "DO" -Unit "ioPluto" -UnitMap "15"
-Name "doPackage0_16" -SignalType "DO" -Unit "ioPluto" -UnitMap "16"
-Name "doPackage0_17" -SignalType "DO" -Unit "ioPluto" -UnitMap "17"
-Name "doPackage0_18" -SignalType "DO" -Unit "ioPluto" -UnitMap "18"
-Name "doPackage0_19" -SignalType "DO" -Unit "ioPluto" -UnitMap "19"
-Name "doPackage0_20" -SignalType "DO" -Unit "ioPluto" -UnitMap "20"
-Name "doPackage0_21" -SignalType "DO" -Unit "ioPluto" -UnitMap "21"
-Name "doPackage0_22" -SignalType "DO" -Unit "ioPluto" -UnitMap "22"
-Name "doPackage0_23" -SignalType "DO" -Unit "ioPluto" -UnitMap "23"
-Name "doPackage0_24" -SignalType "DO" -Unit "ioPluto" -UnitMap "24"
-Name "doPackage0_25" -SignalType "DO" -Unit "ioPluto" -UnitMap "25"
-Name "doPackage0_26" -SignalType "DO" -Unit "ioPluto" -UnitMap "26"
-Name "doPackage0_27" -SignalType "DO" -Unit "ioPluto" -UnitMap "27"
-Name "doPackage0_28" -SignalType "DO" -Unit "ioPluto" -UnitMap "28"
-Name "doPackage0_29" -SignalType "DO" -Unit "ioPluto" -UnitMap "29"
-Name "doPackage0_30" -SignalType "DO" -Unit "ioPluto" -UnitMap "30"
-Name "doPackage0_31" -SignalType "DO" -Unit "ioPluto" -UnitMap "31"
-Name "doPackage0_32" -SignalType "DO" -Unit "ioPluto" -UnitMap "32"
-Name "doPackage0_33" -SignalType "DO" -Unit "ioPluto" -UnitMap "33"
-Name "doPackage0_34" -SignalType "DO" -Unit "ioPluto" -UnitMap "34"
-Name "doPackage0_35" -SignalType "DO" -Unit "ioPluto" -UnitMap "35"
-Name "doPackage0_36" -SignalType "DO" -Unit "ioPluto" -UnitMap "36"
-Name "doPackage0_37" -SignalType "DO" -Unit "ioPluto" -UnitMap "37"
-Name "doPackage0_38" -SignalType "DO" -Unit "ioPluto" -UnitMap "38"
-Name "doPackage0_39" -SignalType "DO" -Unit "ioPluto" -UnitMap "39"
-Name "doPackage0_40" -SignalType "DO" -Unit "ioPluto" -UnitMap "40"
-Name "doPackage0_41" -SignalType "DO" -Unit "ioPluto" -UnitMap "41"
-Name "doPackage0_42" -SignalType "DO" -Unit "ioPluto" -UnitMap "42"
-Name "doPackage0_43" -SignalType "DO" -Unit "ioPluto" -UnitMap "43"
-Name "doPackage0_44" -SignalType "DO" -Unit "ioPluto" -UnitMap "44"
-Name "doPackage0_45" -SignalType "DO" -Unit "ioPluto" -UnitMap "45"
-Name "doPackage0_46" -SignalType "DO" -Unit "ioPluto" -UnitMap "46"

ABB Pluto Series Specifications

General

Mounting	DIN rail
Current consumption	Typically 100 mA
Communication interface	Ethernet
Protocols supported	Modbus TCP, PROFIBUS DP
Enclosure	IP20
Supply voltage	24 VDC
Weight	Approx. 200 g
