ABB PST User Manual

Low Voltage Products & Systems 145
ABB Inc. • 888-385-1221 • www.abb-control.com AC 1006.9 - 5/03
Chapter 10 - Functions
10:51 Programmable software output
V7
Path in menu:
Menu/SETTINGS/Functional Settings/
Outputs/SW Outp V7
If the softstarter is used with fieldbus communication, a fourth output
is available. This is a software output only and the signal can be
taken only through the fieldbus interface.
(See 50 “ Programmable outputs, Relay K4, K5 and K6” for further
explanations.)
Parameter
text
Default
value
Setting
range
Description
Relay K4 Run
Run, TOR,
Event
Function of
program-
mable output
K4
Relay K5 TOR
Run, TOR,
Event
Function of
program-
mable output
K5
Relay K6 Event
Run, TOR,
Event
Function of
program-
mable output
K6
Parameter
text
Default
value
Setting
range
Description
SW Outp V7 Event
Run, TOR,
Event
Function of
program-
mable
software
output V7
