10:66 Current limit, third sequence
Path in menu:
Menu/SETTINGS/Functional Settings/
Seq Start/3rd Seq. Param./Curr Lim3
This parameter makes it possible to set the current limit level for the
third parameter set.
10:67 Setting current, third sequence
Path in menu:
Menu/SETTINGS/Functional Settings/
Seq. Start/3rd Seq. Param./3rd Set Ie
This parameter makes it possible to set the rated motor current for
the third parameter set.
Chapter 10 - Functions
Parameter
text
Default
value
Setting
range
Description
Curr Lim3
4xI
e
2.0… 5.0xI
e
Third
sequence,
current limit
Parameter
text
Default
value
Setting
range
Description
3rd Set Ie Ir
9… 1380A
divided into
19
overlapping
ranges
Third
sequence,
motor rated
current
