5.2.4 Menu - Measurement
When the user selects Measurements sub-menu using right arrow key, an overview
of basic measurements of the relay is visible for each analogue input module.
Measurements like - Phase currents, neutral current, etc. can be seen in this view.
An Up-Down arrow key should be used to switch to the next available screen.
Fig. 12- Measurement menu with its sub menu
Fig. 13- Measurement menu view with primary current
M e a s u r e e n tm
P r i m a r y C u r r e n t
S e c o n d r y C u r r e n t
P r i m a r y C u r r e n t I 1 :
X X X X X . X X A m p
I 2 :
X X X X X . X X A m P
I 3 :
X X X X X . X X A m p
I o :
X X . X X I n
