ABB REF601 CEI User Manual

1MDU07205-YN rev. F
REF601 CEI
User’s manual
22
Technical data
Environmental tests
Shock test IEC60255-21-2
(based on IEC60068-
2-27 test Ea and
IEC60068-2-29 test
Eb)
Shock response test:
Class2. Peak acceleration (A) 10gn,
Duration of the pulse (D) 11ms,
3 pulses in each direction
Shock withstand test:
Class2. Peak acceleration (A) 30gn,
Duration of the pulse (D) 11ms,
3 pulses in each direction
Bump test IEC60255-21-2
(based on IEC60068-
2-27 test Ea and
IEC60068-2-29 test
Eb)
Class2. Peak acceleration (A) 20gn,
Duration of the pulse (D) 16ms,
1000 pulses in each direction
Electrical Insulation and mechanical construction tests
Power-Frequency with-
stand Voltage (Insulation
test voltage)
IEC 60255-5 Level 2, 50Hz, 1min:- 2 kVrms (CM)
Lightening Impulse Volt-
age
IEC 60255-5 Level 3, 1.2/50μs, 500Ω, source Z,
0.5J source energy, - 5kVp (CM )
Insulation resistance IEC 60255-5 500Vdc (CM) test voltage: >100MΩ
Protective bonding
resistance
IEC 60255-27 < 0.1 Ω ( 60 sec )
Electromagnetic Compatibility tests
Emission Test (For test
site measurements,)
IEC 60255-25 30…230MHz:
40dB (μV/m) quasi peak at 10m distance
230…1000MHz:
47dB (μV/m) quasi peak at 10m distance
Power supply Emission IEC 60255-25 0.15…0.5MHz:
79dB (μV/m) quasi peak
66dB (μV/m) average
0.5…30MHz:
73dB (μV/m) quasi peak
60dB (μV/m) average
Conducted Immunity and Power unit tests
Electrostatic Discharge IEC 60255-22-2 Level 3, 5/30ns pulse, 5 discharges:
±6kVp contact
±8kVp air
Fast Low Energy Tran-
sient (EFT) (Including
functional earth port)
IEC 60255-22-4 5/50ns pulse, 2.5 kHz, ±4kVp,
