1MDU07205-YN rev. F
REF601 CEI
User’s manual
23
Technical data
Conducted Immunity and Power unit tests
Slow High Energy Tran-
sient (Surge1.2/50us Volt-
age pulse)
IEC 61000-4-5
IEC 60255-22-5
1.2/50μs pulse
±4kVp (L-Gnd)
±2kVp (L-L)
Radio-Frequency distur-
bance (Including func-
tional earth port)
IEC 60255-22-6 Level 3, 0.15…80MHz, step 1%, AM
80% @ 1kHz,.: 10Vrms/unmod (CM),
Spot freq 27MHz 68Mhz
Voltage Dips.,Short Inter-
ruptions (ac)
IEC 61000-4-11 100% (10mS and 30mS),70% and 40%
Voltage Variation immu-
nity tests (ac)
IEC 61000-4-11 Voltage Test level 70%
Damped Oscillatory
Waves (HFD)
IEC 61000-4-12 Level 3
1 MHz , 10 transients:± 2.5kVp (CM)
, ± 1kVp (DM)
Ripple Voltage IEC 60255-11
IEC 61000-4-17
Level 3: 10% Un
50, 300 Hz ripple freq.
Voltage Drop, Supply
Interruption and voltage
variations on d.c. input
power port (immunity
tests)
IEC61000-4-29 100% @ 50ms
Power Frequency Immu-
nity Test
IEC60255-22-7 Class A :
CM: 300Vrms
DM: 150Vrms
Radiated Immunity Tests
Radio-Frequency Electro-
magnetic Field (Ampli-
tude modulated)
IEC 60255-22-3 80…1000MHz, AM 80% @
1kHz, horizontal and verti-
cal polarization: - 10V/m
Spot freq: 80, 160, 450, 900MHz, AM
80% @1kHz
Radio-Frequency Elec-
tromagnetic Field
from digital radio
telephones(Pulse Modul.)
IEC 60255-22-3 Level 4, 900 ± 5MHz, PWM 100% @
200Hz, 50% D.C.: - 10V/m (10s Dwell
time)
