ABB REF601 CEI - EMC compliance; Product safety; Data communication (optional)

1MDU07205-YN rev. F
REF601 CEI
User’s manual
24
Technical data
Magnetic immunity tests
Power-Frequency
Magnetic Field
IEC 61000-4-8 Level 5, X-Y-Z axis :
-100A/m continuously
-1000A/m short time
Pulse Magnetic Field IEC 61000-4-9 Level 5, 5 positive and 5 negative,
8/20μs pulses every 10s:- 1000 A/m
Contact tests
Make and carry IEC 60255-23
(Replaced by
IEC61810-2,
Ed.1.0)
Signaling : 10A@24VDC for
0.5s and 8A@24VDC for 3s
Tripping : 30A@24V DC for 0.5S and
15A@24VDC for 3S
Breaking capacity for
d.c., L/R ≤ 40 ms
IEC 60255-23 Signaling: 0.15A@220VDC
and 4.5A @30VDC
Tripping: 0.2A@220VDC and
5.5A@35VDC
Make and Break capacity
for resistive load
IEC 60255-23 Signaling: 6A @240V ac
Tripping: 8A@240V ac
Mechanical durability IEC 60255-6 10,000 operations ; tripping and sign-
aling contacts
EMC compliance
Complies with the EMC directive 2004/108/EC
Standards EN 60255-26 (2004)
RoHS compliance
Complies with the RoHS directive 2002/95/EC
Data communication ( optional )
Protocol : Modbus RTU
Communication port : RS485 4-wire
Product safety
Complies with the LV directive 2006/95/EC
Standards EN 60255-27 (2005),
EN 60255-6 (1994)
