Following table shows the functional test group parameter values.
Menu structure & LHMI Navigation
SG Parameter SG Parameter
1
Curve: VI
K = 0.1
I> = 0.2 In
10
Curve: DT
I0> = 0.2 In
t0> = 0.2 sec
2
Curve: VI
K = 0.1
I> = 0.5 In
11
Curve: DT
I0> = 0.5 In
t0> = 0.05 sec
3
Curve: VI
K = 0.1
I> = 1.2 In
12
Curve: DT
I0> = 0.1 In
t0> = 0.2 sec
4
I>>> = 0.8 In
t>>> = 0.05 sec
13
Curve: DT
I0> = 0.025 In
t0> = 0.05 sec
5
I>>> = 5.0 In
t>>> = 0.05 sec
14
Curve: DT
I0> = 0.4 In
t0> = 0.3 sec
6
I>>> = 5.0 In
t>>> = 0.2 sec
15
I0>> = 0.25 In
t0>> = 0.05 sec
7
I>> = 0.2 In
t>> = 0.05 sec
16
I0>> = 1.0 In
t0>> = 0.2 sec
8
I>> = 2.1 In
t>> = 0.3 sec
17
I0>> = 2.0 In
t0>> = 0.1 sec
9
I>> = 4.2 In
t>> = 0.5 sec
