5. Check the default settings in the SCL Import view and change the settings if
they are not suitable.
The default settings in the SCL Import dialog should be correct in most cases.
6. Click Import to import the SCD file.
7. Check the IP address on the IEC 61850 subnetwork and change it if needed.
When the SCD file is directly exported from PCM600, it uses the IP address of
the PCM600 computer, not the COM600S.
The communication towards the protection relays is now ready. For information on
how to finalize the single-line diagram and enable parameter setting through
COM600S HMI, see COM600S documentation.
4.6 Using the Web HMI
WHMI is enabled by default. As secure communication is enabled by default, the
WHMI must be accessed from a Web browser using the HTTPS protocol.
If the WHMI was previously disabled, it can be enabled again via the LHMI.
1. To enable the WHMI, select Main menu/Configuration/HMI/Web HMI
mode via the LHMI.
2. Reboot the relay for the change to take effect.
3. Log in with the proper user rights to use the WHMI.
To establish a remote WHMI connection to the protection relay,
contact the network administrator to check the company rules for IP
and remote connections.
Disable the Web browser proxy settings or make an exception to the
proxy rules to allow the protection relay's WHMI connection, for
example, by including the relay's IP address in Internet Options/
Connections/LAN Settings/Advanced/Exceptions.
For more information on the WHMI, see the operation manual.
4.7 Managing IED users
IED user authorization is disabled by default. IED user passwords can be changed in
LHMI, WHMI and using the IED Users tool in PCM600.
