Action Description
Close Clicking the Close button closes this instance of the Fault Record tool. Any open
instance is finally closed when the whole PCM600 is closed.
File File menu for Save and Exit actions.
Edit Copy All in the Edit menu allows to copy all the fault records which can then be
pasted to a word processor and saved on the local machine without having to save
the records as a .txt file.
Additionally the user can select any particular fault record and right-click to copy the
selected record.
5.4 IED Compare
IED Compare is used to compare the IED configurations of two IEDs of the same type.
It generates a text report which lists the differences between the IED configurations.
IED Compare provides an option to compare an IED configuration stored in
PCM600, IED or .pcmi file. IED Compare can compare certain types of IED
configurations and parameters.
• Display configuration
• GOOSE receive configuration
• Parameters
Display comparison compares two display pages with a delta of two
pixels.
Detailed instructions are shown in PCM600 documentation.
5.4.1 Starting IED Compare
• Start IED Compare in the shortcut menu in plant structure.
1. In the PCM600 plant structure, right-click Substation, Voltage level, Bay
or IED.
2. Select IED Compare.
• Start IED Compare from the PCM600 main menu.
1. Select Substation, Voltage level, Bay or IED in the PCM600 plant
structure.
2. On the PCM600 menu bar, point to Tools and select IED Compare.
