1.
Create a project in an IEC 61850 configuration tool.
[1]
2.
Import the SCD file created by PCM600.
[1]
3. Conduct vertical communication engineering (monitoring direction).
3.1. Check the default data sets.
3.2. Configure and/or reconfigure the default data sets.
Data sets meant for vertical reporting can only contain data
on the data object level, not on the data attribute level.
The data set for GOOSE can contain signals only on the
data attribute level.
3.3. Configure additional Report Control Blocks when needed for each data set
used for vertical communication.
3.4. Link the IED clients to the Report Control Blocks.
Up to five report clients can be configured.
4. Conduct horizontal communication engineering.
4.1. Configure GOOSE control blocks for each data set configured for GOOSE
messages.
One data can be included in the GOOSE data set only once.
4.2. Define the client IEDs for each GOOSE control block.
4.3. Link the IEDs to the GOOSE control block that is to receive the GOOSE
control block.
5.
Export the updated SCD file.
[1]
All data sets, Report Control Blocks and GOOSE control blocks
must be located in LLN0.
[1] Applicable when using IET600
Section 7 1MRS240044-IB A
IEC 61850 communication engineering
106 REF615R
Engineering Manual
