Section 6 LHMI engineering
For information on LED operation modes supported by the IED, see the
technical manual.
6.1 Single-line diagram engineering
A single-line diagram of the IED can be designed by using the Graphical Display
Editor tool of PCM600. The single-line diagram is modelled according to the IEC
61850 standard in the Graphical Display Editor.
6.1.1 Diagrams in Graphical Display Editor
The Graphical Display Editor is used for various tasks.
• HMI display raster layouts
• Adding static text
• Adding measurands
• Adding busbars
• Adding symbols onto display page
• Drawing lines (creating a link)
• Adding buttons to control ACT application with SPCGGIO
