A progress view displays the importing procedure.
6. Make connections from the sending IEDs to the receiving function blocks with
the Signal Matrix tool.
Make connections between the signals that the server is sending and the function
blocks on the receiver's side.
7. Write the configuration to the IED.
In the Plant Structure view, select the IED, right-click and select Write to IED.
Section 7 1MRS240044-IB A
IEC 61850 communication engineering
108 REF615R
Engineering Manual
