configuration is changed, but no changes are done to the instantiation or deletion of
functions that represent a logical node.
When a changed configuration is written to the IED, you are asked to update the
communication configuration.
GUID-EEB7D9BD-5D8C-4A18-9A94-848B2821658D V1 EN
Figure 70: Updating the communication configuration in the IED with the
configuration made in PCM600
1. Select whether or not to update the configuration.
• Click Yes in the Update Communication window to update the
communication configuration part in the IED.
• Click No in the Update Communication window to keep the
communication configuration part in the IED. Other parts of the
configuration will be updated.
If no changes have been done in the communication configuration
part, click No in the Update Communication window.
1MRS240044-IB A Section 7
IEC 61850 communication engineering
REF615R 111
Engineering Manual
