configuration tools. The single-line diagram can also be modified with Graphical
Display Editor.
All functions and application logic included in a standard configuration of the IED can
be in use at the same time.
However, by removing unused function blocks from the configuration with the
Application Configuration in PCM600, more resources in the IED become available
for other purposes.
• More advanced user application logic with Application Configuration
• Extensive use of GOOSE sending and receiving
• Increasing the amount of data reported for IEC 61850 clients
Section 2 1MRS240044-IB A
IED engineering process
18 REF615R
Engineering Manual
