ABB REG670 - High Speed Distance Protection ZMFPDIS

Z
R
e
v
P
P
ZAngPP
}
}
Z
P
P
X
R
IEC10000105-1-en.vsd
IEC10000105 V1 EN
Figure 79: Operating characteristic for phase-to-phase loops
8.2 High speed distance protection ZMFPDIS
ZMFPDIS can be used according to the application description below
only if VT and CT of the line feeder are wired to REG670.
8.2.1 Identification
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
High speed distance protection zone ZMFPDIS
S00346 V1 EN
21
1MRK 502 071-UEN - Section 8
Impedance protection
Generator protection REG670 2.2 IEC and Injection equipment REX060, REX061, REX062 187
Application manual
