Function block with user defined functions in control direction, I103UserCMD. These
function blocks include the FUNCTION TYPE parameter for each block in the private
range, and the INFORMATION NUMBER parameter for each output signal.
Status
For more information on the function blocks below, refer to the
Communication protocol manual, IEC 60870-5-103.
The events created in the IED available for the IEC 60870-5-103 protocol are based
on the:
• IED status indication in monitor direction
Function block with defined IED functions in monitor direction, I103IED. This block
use PARAMETER as FUNCTION TYPE, and INFORMATION NUMBER
parameter is defined for each input signal.
• Function status indication in monitor direction, user-defined
Function blocks with user defined input signals in monitor direction, I103UserDef.
These function blocks include the FUNCTION TYPE parameter for each block in the
private range, and the INFORMATION NUMBER parameter for each input signal.
• Supervision indications in monitor direction
Function block with defined functions for supervision indications in monitor
direction, I103Superv. This block includes the FUNCTION TYPE parameter, and the
INFORMATION NUMBER parameter is defined for each output signal.
• Earth fault indications in monitor direction
Function block with defined functions for earth fault indications in monitor direction,
I103EF. This block includes the FUNCTION TYPE parameter, and the
INFORMATION NUMBER parameter is defined for each output signal.
• Fault indications in monitor direction
Function block with defined functions for fault indications in monitor direction,
I103FLTPROT. This block includes the FUNCTION TYPE parameter, and the
INFORMATION NUMBER parameter is defined for each input signal.
This block is suitable for distance protection, line differential, transformer
differential, over-current and earth-fault protection functions.
• Autorecloser indications in monitor direction
