GUID-B680F7EA-7387-444C-AB88-5732E7C4AB47-ANSI V1 EN
Figure 45: Monitoring events
2. Click Freeze to stop updating the event list.
3. Select a page from the drop-down list to view older documents.
4. To save the events in the CSV file format, click Save and copy the CSV content to
text editor and save in the CSV file format.
The CSV file can be opened with a spreadsheet program such as
OpenOffice.org Calc or Microsoft Excel.
5. Click Clear events to clear all events from the protection relay.
4.2.12 Selecting DFR records view
DFR records are listed in the DFR records view.
• Click DFR records on the menu bar.
1MAC456939-IB D Section 4
Using the HMI
620 series ANSI 67
Operation Manual
