Indicator Description
P2-kW Active power, magnitude of instantaneous value
S2-kVA Apparent power, magnitude of instantaneous value
Q2-kVAr Reactive power, magnitude of instantaneous value
IG-A Measured residual current
VG-kV Measured residual voltage
PFA Power factor, magnitude of instantaneous value, phase A
PFB Power factor, magnitude of instantaneous value, phase B
PFC Power factor, magnitude of instantaneous value, phase C
PA-kW Active power, magnitude of instantaneous value, phase A
PB-kW Active power, magnitude of instantaneous value, phase B
PC-kW Active power, magnitude of instantaneous value, phase C
SA-kVA Apparent power, magnitude of instantaneous value, phase A
SB-kVA Apparent power, magnitude of instantaneous value, phase B
SC-kVA Apparent power, magnitude of instantaneous value, phase C
QA-kVAr Reactive power, magnitude of instantaneous value, phase A
QB-kVAr Reactive power, magnitude of instantaneous value, phase B
QC-kVAr Reactive power, magnitude of instantaneous value, phase C
PFA2 Power factor, magnitude of instantaneous value, phase A
PFB2 Power factor, magnitude of instantaneous value, phase B
PFC2 Power factor, magnitude of instantaneous value, phase C
PA2-kW Active power, magnitude of instantaneous value, phase A
PB2-kW Active power, magnitude of instantaneous value, phase B
PC2-kW Active power, magnitude of instantaneous value, phase C
SA2-kVA Apparent power, magnitude of instantaneous value, phase A
SB2-kVA Apparent power, magnitude of instantaneous value, phase B
SC2-kVA Apparent power, magnitude of instantaneous value, phase C
QA2-kVAr Reactive power, magnitude of instantaneous value, phase A
QB2-kVAr Reactive power, magnitude of instantaneous value, phase B
QC2-kVAr Reactive power, magnitude of instantaneous value, phase C
VAB-kV Measured phase-to-phase voltage amplitude phase AB
VBC-kV Measured phase-to-phase voltage amplitude phase BC
VCA-kV Measured phase-to-phase voltage amplitude phase CA
VAB2-kV Measured phase-to-phase voltage amplitude phase AB
VBC2-kV Measured phase-to-phase voltage amplitude phase BC
VCA2-kV Measured phase-to-phase voltage amplitude phase CA
V1-kV Measured positive-sequence voltage
Table continues on next page
Section 6 1MAC456939-IB D
Operating procedures
84 620 series ANSI
Operation Manual
