7 Commissioning
7.1 Commissioning checklist
Familiarize yourself with the protection relay and its functionality before you start
the commissioning work.
• Ensure that you have all the needed station drawings such as single line and
wiring diagrams.
• Ensure that your version of the technical manual applies to the protection relay
version you test.
• Ensure that your setting software and connectivity packages work with the
protection relay version you test.
• Find out if you need any additional software.
• Ensure that you have the relay settings either on paper or in electronic format.
The settings and logic should be well documented.
• Inspect the settings to ensure that they are correct.
• Ensure that you have the correct cable to connect your PC to the protection
relay's communication port. The RJ-45 port supports any CAT 5 Ethernet cable
but the recommendation is STP.
• Test your PC's communication port before you go to the site.
• Find out who to contact if you have trouble and make sure you have a means to
contact them.
• Find out who is responsible for the settings.
• Ensure that you have with you the proper test equipment and all needed
connection cables.
• Ensure that the owner of the switchgear familiarizes you with the work site and
any special aspects of it.
• Ensure that you know how to operate in emergency situations. Find out where
the first aid and safety materials and exit routes are.
Ensure that self-supervision is not indicating active internal faults before
starting commissioning work.
7.2 Checking installation
7.2.1 Checking power supply
• Check the following for both the relay and LHMI, if used.
- The auxiliary supply voltage must remain within the permissible input voltage
range under all operating conditions.
