4. Technical keys of the IEDs in the PCM600 project are configured to match the
technical keys of the physical IEDs.
For successful protection relay engineering and usage, the workstation firewall
TCP and UDP port configurations should be checked, especially for IEC 61850
and FTP. Other protocols are not used for engineering or they are optional.
Table 14: IP ports used by the relay
Port number Type Default state Description
21 TCP Open Explicit FTP over TLS
22 TCP Closed SSH (HMI only, normally
closed)
102 TCP Open IEC 61850
443 TCP Open Web server HTTPS
123 UDP Client service not active
by default in relay
SNTP
502 TCP Closed Modbus TCP
2404 TCP Closed IEC 60870-5-104 TCP
20000 TCP Closed DNP3 TCP
20000 UDP Closed DNP3 UDP
1468 TCP Closed CAL
514 UDP Closed CAL
49220...49235 TCP Closed Ports open on demand for
data transfer when FTP
PASV command is given
7.4.2 Communication settings
7.4.2.1 Ethernet ports
The protection relay allows the use of a secondary IP address for the station ports
on the communication modules COM1001...COM1003. This secondary IP network is
assigned to a single Ethernet port and can be used to make separate networks
for different communication protocols or, for example, a separate service network
for configuration purposes. Multicast station/bus communication, such as IEC
61850-9-2 LE sampled values and GOOSE, is only supported on the Network 1
interface. The parameters for setting the secondary IP network are located under
Configuration> Communication> Ethernet> Network 2 address.
Commissioning
1MRS759118 D
116 REX640
Operation Manual
