5.8 Measurements and phasor diagrams
5.8.1 Viewing measurements
1. Select Measurements on the menu bar.
2. Select Measurements from the drop-down list.
Figure 52: Viewing measurements
Measurements are also displayed in the Dashboard view.
5.8.2 Viewing phasor diagrams
1. Select Measurements on the menu bar.
2. Select Phasor Diagrams from the drop-down list.
Figure 53: Monitoring phasors
