visualized format on the Testing and Commissioning pages found on the top bar
menu.
HMI client can be opened from PCM600.
Some of the Testing and Commissioning pages require the relay to be set
in test mode.
Figure 118: Home page for Testing and Commissioning pages
7.5.2.1 Testingl I/O interface
1. On the View I/O page, monitor the status of digital inputs and outputs and
analog inputs.
1MRS759118 D
Commissioning
REX640
Operation Manual
139
