Fault indication
Fault
code
Additional
information
Fast self-
recovery
attempt
Slow 10min
self-
recovery
(# of
attempts)
Immediate
IRF-mode
Action in permanent fault
state
change the hardware mod-
ule in slot C.
Internal Fault
Conf. error, Slot
E
-31 Start up error: Card
in slot E is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the card in slot
E is proper type and prop-
erly installed. Then restart
the relay. If does not then
recover by restarting, it
is hardware module failure
most likely in question. Ex-
change the hardware mod-
ule in slot E.
Internal Fault
Conf. error, Slot
A2
-32 Start up error: Card
in slot A2 is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the communica-
tion card in slot A2 is prop-
er type and properly instal-
led. Then restart the relay.
If does not then recover by
restarting, it is hardware
module failure most likely
in question. Exchange the
communication module in
slot A2.
Internal Fault
Conf. error, Slot
B
-33 Start up error: Card
in slot B is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the card in slot
B is proper type and prop-
erly installed. Then restart
the relay. If does not then
recover by restarting, it
is hardware module failure
most likely in question. Ex-
change the hardware mod-
ule in slot B.
Internal Fault
Conf. error, Slot
D
-34 Start up error: Card
in slot D is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the card in slot
D is proper type and prop-
erly installed. Then restart
the relay. If does not then
recover by restarting, it
is hardware module failure
most likely in question. Ex-
change the hardware mod-
ule in slot D.
Internal Fault
Conf. error, Slot
F
-35 Start up error: Card
in slot F is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the card in slot
F is proper type and prop-
erly installed. Then restart
the relay. If does not then
recover by restarting, it
is hardware module failure
most likely in question. Ex-
change the hardware mod-
ule in slot F.
Internal Fault
Conf. error, Slot
G
-36 Start up error: Card
in slot G is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the card in slot
G is proper type and prop-
erly installed. Then restart
the relay. If does not then
recover by restarting, it
is hardware module failure
most likely in question. Ex-
change the hardware mod-
ule in slot G.
Internal Fault
Conf. error, Slot
A1
-37 Start up error: Card
in slot A1 is wrong
type, is missing,
does not belong
to original configu-
ration or card firm-
ware is faulty.
No No Yes Check that the card in slot
A1 is proper type and prop-
erly installed. Then restart
the relay. If does not then
recover by restarting, it
is hardware module failure
most likely in question. Ex-
Table continues on the next page
