ABB RETA-01 - Page 25

Quick start-up guide
25
Table 5. Drive configuration for Extended Speed Control
Drive parameter Example setting for ACS800
10.01 EXT1 STRT/STP/DIR COMM.CW
10.03 REF DIRECTION REQUEST
11.03 EXT1 REF1 SELECT COMM.REF
16.04 FAULT RESET SEL COMM.CW
98.02 COMM. MODULE LINK FIELDBUS
98.07 COMM PROFILE GENERIC
51.01 MODULE TYPE ETHERNET
51.02 COMM RATE 0 (Auto-negotiation)
51.03 DHCP 1 (Enabled)
51.04 - 51.07 IP ADDRESS 10.0.0.6
51.08 - 51.11 SUBNET MASK 255.255.255.0
51.12 - 51.15 GW ADDRESS 0.0.0.0
51.16 PROTOCOL 1 (AC/DC profile)
