ABB SACE Tmax XT2 User Manual

1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 10
Ekip M Touch
Figure 6
Ekip M Touch is available in one version: Ekip M Touch LRIU has default functions that can be
expanded with additional software packages (extensions).
Default
Function
Page
Standard Protections
35
Standard Sizes
96
Measuring
100
Voltage Protections
46
Frequency Protections
54
Power Protections
(1)
57
Adaptive Protections
65
Motor Protections
66
Additional SW packages
Function
Page
Advanced Voltage Protections
50
Power Protections
(1)
57
ROCOF Protections
64
Class 1 Power & Energy Metering
(2)
103
Datalogger
104
Network Analyzer
106
NOTES:
(1) By default Ekip M Touch has some protections from the complete package; the
remaining protections in the package can be enabled upon request.
(2) package available only when ordering the circuit breaker
