Ekip Touch
Measuring
Figure 4
Ekip Touch Measuring is available in two versions: Ekip Touch Measuring LSI and Ekip Touch
Measuring LSIG.
Both versions have default functions and can be configured with various additional software
packages (extensions).
Default
Function
Page
Standard Protections
35
Standard Sizes
96
Measuring
100
Additional SW packages
Function
Page
Voltage Protections
46
Advanced Voltage Protections
50
Frequency Protections
54
Power Protections
57
ROCOF Protections
64
Adaptive Protections
65
Class 1 Power & Energy Metering
(NOTE)
103
NOTE: package available only when ordering the circuit breaker
