Page #102 background imageLoading...
Page #102 background image
Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 102
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
2. SYNCHROTACT 5 is not in error status, but the synchronizing process cannot be
started, takes a very long time or paralleling does not take place:
1. SYNCHROTACT 5 is blocked: the BLOCKED LED lights up: the device is not
ready for operation (e.g. following manipulation of the settings) or TEST mode is
selected (only possible with the “7 parameter sets” option)
2. SYNCHROTACT 5 is ready (READY LED) or in operation (OPERATING LED):
temporarily set parameter t tot to a low value (e.g. 1 minute). On a further
attempt, the synchronizing process will be aborted after the set time. Read error
codes from the LCD or using SynView and proceed in accordance with section
9.2.3
3. Faults in connection with a communication interface: refer to section 9.3
If this advice does not lead to success, proceed in accordance with section 9.2.4.
9.2.3 Fault and event table
On the LCD, the code of the last detected fault is displayed. A description of the codes
can be found in the following table. “Older” faults can be viewed using the keypad. In the
case of devices without a built-in control unit, in the event of a fault the error messages
can be read out in plain text using the PC tool
SynView.
Events
Code
Description Remarks
001 Auxiliary voltage on After the electronics power supply is connected
003 SYNCHROTACT selected After the Start pulse
004 SYNCHROTACT stopped After the Stop pulse
005 Device ready SYNCHROTACT 5 is ready for operation
006 Device not ready SYNCHROTACT 5 is blocked.
without error = service operation; with error = fault
011 Data change This event is displayed when the device changes from READY
or OPERATING status into BLOCKED status, i.e. following a
write or blocking command
021 Adjusting command U+ Higher voltage adjusting command
022 Adjusting command U- Lower voltage adjusting command
023 Adjusting command f+ Higher frequency adjusting command
024 Adjusting command f- Lower frequency adjusting command
025 Release contact closes Output contact of channel 2 (synchrocheck)
026 Release contact opens Output contact of channel 2 (synchrocheck)
027 Paralleling command
contact closes
Issue of a paralleling command by the command generation
(in synchrocheck mode: paralleling release)
028 Paralleling command
contact opens
End of the paralleling command (in synchrocheck mode : end
of paralleling release)
029 Blocking active Blocking signal to one of the configurable inputs has
interrupted synchronizing process.
030 Blocking cancelled Blocking signal has released the synchronizing process again.
031 Operating control interface
blocked
Input BLK REM active; local control only
