Operating Instructions SYN 5201/SYN 5202

Document No Art Part Language Revision page

abb

ABB Switzerland Ltd

3BHS109762 E01

en D 60

Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q

4.3.8 SYNCHROTACT 5 - specific logical nodes and their application

LN Contents Remarks DR GR

RSYN10 General Data Standard Yes No

RSYN21 Paralleling point 1 Standard Yes Yes

RSYN22 Paralleling point 2 Option 7 Parameter sets Yes Yes

RSYN23 Paralleling point 3 Option 7 Parameter sets Yes Yes

RSYN24 Paralleling point 4 Option 7 Parameter sets Yes Yes

RSYN25 Paralleling point 5 Option 7 Parameter sets Yes Yes

RSYN26 Paralleling point 6 Option 7 Parameter sets Yes Yes

RSYN27 Paralleling point 7 Option 7 Parameter sets Yes Yes

RSYN31 Parameter set 1 Standard No No

RSYN32 Parameter set 2 Option 7 Parameter sets No No

RSYN33 Parameter set 3 Option 7 Parameter sets No No

RSYN34 Parameter set 4 Option 7 Parameter sets No No

RSYN35 Parameter set 5 Option 7 Parameter sets No No

RSYN36 Parameter set 6 Option 7 Parameter sets No No

RSYN37 Parameter set 7 Option 7 Parameter sets No No

RSYN40 Parameters channel 2 Only SYN 5202 No No

SYNGGIO51 Digital Inputs 1-5 Option 7 Parameter sets Yes No

SYNGGIO52 Digital Inputs 6-7 Option 7 Parameter sets Yes No

SYNGGIO61 Digital Outputs 1-5 Option 7 Parameter sets Yes No

SYNGGIO62 Digital Outputs 6-7 Option 7 Parameter sets Yes No

DR = Data Report; Attributes, which are not included in a report must be read out. ("polling")

GR = GOOSE Report
