ABB SYNCHROTACT 5 User Manual

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 61
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
Logical Node RSYN10
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Controls
StrSynPrg START
Yes
No
StopSynPrg STOP
Yes
No
RelDeaBus RELEASE DB
Yes
No
BlkSyn BLOCK
Yes
No
RsSyn RESET
Yes
No
Status Information
Rel CHK RELEASE
Display paralleling release im
Synchrocheckbetrieb
Yes
No
Cmd COMMAND
Display paralleling command
issue
Yes
No
VInd ΔU < ΔUmax
IEC 61850-Signal is inverted
Yes
No
AngInd α < αmax
IEC 61850-Signal is inverted
Yes
No
HzInd s < smax
IEC 61850-Signal is inverted
Yes
No
SynPrg OPERATING
Yes
No
SynFlt ERROR
Yes
No
SynRdy READY
Yes
No
SynSetMod BLOCKED
Yes
No
Measured Values
DifVClc ΔU
No No
DifHzClc s
No No
DifAngClc α
No No
V1Clc U1
No No
V2Clc U2
No No
Hz1Clc f1
No No
Hz2Clc f2
No No
AccClc ds/dt
No No
Logical Node RSYN21 to RSYN27
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Status Information
Rel CHK RELEASE
Only when paralleling point is selected.
With SYN 5202 and SYN 5302,
CHK RELEASE is additionally linked to
CHK RELEASE of the second channel.
Yes Yes
Cmd COMMAND
Only when paralleling point is selected.
Pulse length is limited
With SYN 5202 and SYN 5302,
COMMAND is additionally linked to
CHK RELEASE of the second channel.
Yes Yes
RV U+ Only when paralleling point is selected Yes Yes
LV U- Only when paralleling point is selected Yes Yes
RHz f+ Only when paralleling point is selected Yes Yes
LHz f- Only when paralleling point is selected Yes Yes
SynPrg OPERATING Only when paralleling point is selected Yes No
DR = Data Report; Attributes, that are not contained in a report, must be polled
GR = GOOSE Report
