ABB SYNCHROTACT 5 User Manual

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 62
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
Logical Node RSYN31 to RSYN37
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Settings
VNomV Un
No No
HzNom fn
No No
VAdpFact
UOffset
No No
AdpAngDeg
Offset
No No
BkrTmms t on
No No
PlsTmms tp on
No No
DlTms t supervis
No No
MltCmd
MULTIPLE CMD
No No
DifVNg
-Umax
No No
DifVPs
+Umax
No No
DifHzNg -smax
No No
DifHzPs +smax
No No
DifAngNg
-max
No No
DifAngPs
+max
No No
MinVSyn Umin
No No
MaxVSyn Umax
No No
LivDeaMod
U1not, U2not,
1*2not
LivDeaMod U1not U2not 1*2not
0 0 0 0
1 0 0 1
2 0 1 0
3 1 0 0
No No
4 0 1 1
5 1 0 1
6 1 1 0
7 1 1 1
DeaBusVal U0max
No No
VChr dU/dt
No No
VInvTms ts U
No No
MinVTms tp Umin
No No
HzChr df/dt
No No
HzInvTms ts f
No No
MinHzTms tp fmin
No No
TmTot t tot
No No
DR = Data Report; Attributes that are not contained in a report must be polled
GR = GOOSE Report
