Page #34 background imageLoading...
Page #34 background image
Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 34
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
4.1.5 Configuration parameters “Config parameters“ (option)
These allow different functions to be assigned to the inputs and outputs (see also
section 4.2.8 and 5.4).
“Digital inputs “
No. Parameter name Symbol Range/resolution Unit Default setting
1. Digital input 1 I 1 0 to 32 - 1
2. Digital input 2 I 2 0 to 32 - 2
3. Digital input 3 I 3 0 to 32 - 3
4. Digital input 4 I 4 0 to 32 - 4
5. Digital input 5 I 5 0 to 32 - 5
6. Digital input 6 I 6 0 to 32 - 6
7. Digital input 7 I 7 0 to 32 - 14
“Digital outputs “
No. Parameter name Symbol Range/resolution Unit Default setting
1. Digital output 1 O 1 0 to 32 - 1
2. Digital output 2 O 2 0 to 32 - 2
3. Digital output 3 O 3 0 to 32 - 3
4. Digital output 4 O 4 0 to 32 - 4
5. Digital output 5 O 5 0 to 32 - 5
6. Digital output 6 O 6 0 to 32 - 6
7. Digital output 7 O 7 0 to 32 - 15
4.1.6 Synchrocheck parameters (SYN 5202 only)
These are the parameters for the second channel.
Synchrocheck parameters “synchrocheck param “
No. Parameter name Symbol Range/resolution Unit Default setting
1. Slip limit smax 0.1 to 2.0 % 0.5
2. Angle limit
max
5 to 40/5 DEG 15
3. Maximum
voltage difference
Umax
5 to 40/5 % 5
4. Maximum zero voltage U0max 0 to 50/5 % 50
5. Nominal voltage Un 50 to 130/5 VAC 110
4.1.7 Linking of the parameter sets in dual channel systems
The parameter set of the second channel is linked with the active parameter set of the
first channel.
S01002
SYN 5202/ SYN 5302
Synchrocheck
Channel 1
Parameter set 1
Parameter set 2
Parameter set 3
Parameter set 4
Parameter set 5
Parameter set 6
Parameter set 7
Channel 2
