ABB SYNCHROTACT 5 User Manual

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 63
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
Logical Node RSYN40
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Settings
VNomV Un
No No
DifVPs
Umax
No No
DifHzPs smax No No
DifAngPs
max
No No
DeaBusVal U0max No No
Logical Node SYNGGIO51
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Controls
SPCS01 IN1 Yes No
SPCS02 IN2 Yes No
SPCS03 IN3 Yes No
SPCS04 IN4 Yes No
SPCS05 IN5 Yes No
Logical Node SYNGGIO52
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Controls
SPCS01 IN6 Yes No
SPCS02 IN7 Yes No
Logical Node SYNGGIO61
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Status Information
SPCS01 OUT1 Yes No
SPCS02 OUT2 Yes No
SPCS03 OUT3 Yes No
SPCS04 OUT4 Yes No
SPCS05 OUT5 Yes No
Logical Node SYNGGIO62
IEC 61850
Attribute names
SYNCHROTACT 5
Names
Remarks DR GR
Status Information
SPCS01 OUT6 Yes No
SPCS02 OUT7 Yes No
DR = Data Report; Attributes that are not contained in a report must be polled
GR = GOOSE Report
