Resolution of the bit-coded words into individual binary signals:
Address 1 (Index 0):
Bit Binary signal
0 Start
1 Stop
2 Release DB
3 Reset (cancel fault and set to "READY")
4 Blocking input BLK REM (read only!)
5 --
6 --
7 --
8 Configurable digital input 1 (only with SYN 5014)
9 Configurable digital input 2 (only with SYN 5014)
10 Configurable digital input 3 (only with SYN 5014)
11 Configurable digital input 4 (only with SYN 5014)
12 Configurable digital input 5 (only with SYN 5014)
13 Configurable digital input 6 (only with SYN 5014)
14 Configurable digital input 7 (only with SYN 5014)
15 --
Address 2 (Index 1):
Bit Binary signal
0
LED ‘
U<Umax‘
1 LED ‘s<smax‘
2
LED ‘
<max‘
3 LED ‘U1/U2=0‘
4 --
5 --
6 --
7 --
8 Relay for configurable digital output 1
9 Relay for configurable digital output 2
10 Relay for configurable digital output 3
11 Relay for configurable digital output 4
12 Relay for configurable digital output 5
13 Relay for configurable digital output 6
14 Relay for configurable digital output 7
15 --
Address 3 (Index 2):
Bit Binary signal
0 LED ‘ERROR‘
1 LED ‘BLOCKED‘
2 LED ‘READY‘
3 LED ‘OPERATING‘
4 LED ‘U+‘
5 LED ‘U-‘
6 LED ‘f+‘
7 LED ‘f-‘
8 LED ‘COMMAND‘
9 LED ‘CHK RELEASE‘
10 ‘COMMAND‘ relay
11 --
12 --
13 --
14 --
15 --
