Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 105
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
Error
Code
Description Remarks Remedy
080 Contact monitoring
triggered
The paralleling
command contacts have
not opened again
following the last
command!
Caution: Ensure that the circuit
breaker does not close
accidentally! Check paralleling
command circuits
081 Active Start signal blocks
switchover to “Ready”
SYNCHROTACT 5 can
only be brought into
Ready status if no Start
signal is active.
Cancel Start signal
082 Active blocking signal
prevents Start
Blocking signal must
have dropped on rising
edge of the Start signal
Cancel blocking signal
Parameter set selection
Code
Description Remarks
101 Select parameter set 1 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
102 Select parameter set 2 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
103 Select parameter set 3 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
104 Select parameter set 4 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
105 Select parameter set 5 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
106 Select parameter set 6 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
107 Select parameter set 7 The display appears immediately after the Start command
(<1 s) or if the corresponding signal is active in “Blocked“
status
