ABB SYNCHROTACT 5 User Manual

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 74
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
5.6.3 IEC 61850 - Interface
The ICD-File contains the data model, resp. describes the functionality of the according
SYNCHROTACT 5 – device. An IEC 61850 System Engineering Tool configures the
ICD-Files of all participants in a specific application and their connections among each
other and deposits them in a SCD-File.
The SYN61850Config-Tool can finally download the SCD-File to the SYNCHROTACT 5
– device.
SYN61850Config-Tool
IED
y
IED
x
Communication and Application System
Engineering Tool
S10003
IED
SYNCHROTACT
Application z
ICD-File
SYNCHROTACT 5
SCD-File
Application z
The data sets are fix and must not be changed at any time, neither during configuration
time nor during operation (see also tables with logical nodes in chapter 4.3.8).
