4.3.3 Addressing Profibus DP
28 words, each with 16 bits, are transmitted. The addressing is as follows:
Add-
ress
Content Word type Direction
of trans-
mission
Format Scaling
1 Digital inputs Bit-coded
read and
write*
-- --
2 Digital outputs Bit-coded read -- --
3 Digital outputs Bit-coded read -- --
4
Actual value U
A
nalog value
read signed integer** 0.1 % of Un
5
Actual value 
A
nalog value
read signed integer 0.1 DEG
6 Actual value s
A
nalog value
read signed integer 0.01 %
7 Actual value U1
A
nalog value
read signed integer 0.1 % of Un
8 Actual value U2
A
nalog value
read signed integer 0.1 % of Un
9 Actual value f1
A
nalog value
read signed integer 0.01 Hz
10 Actual value f2
A
nalog value
read signed integer 0.01 Hz
11 Actual value ds/dt
A
nalog value
read signed integer 0.01 %/s
12 Back-indication of selected
parameter set
A
nalog value
read unsigned integer
***
Number of the selected
parameter set
13 Software version
A
nalog value
read unsigned integer One digit of the version
number per nibble (half
byte)
(e.g.: 5137d = 1411h =
V1.4.1.1)
14
Command counter reading parameter set 1
A
nalog value
read unsigned integer none (0 to 65535)
15
Command counter reading parameter set 2
A
nalog value
read unsigned integer none (0 to 65535)
16
Command counter reading parameter set 3
A
nalog value
read unsigned integer none (0 to 65535)
17
Command counter reading parameter set 4
A
nalog value
read unsigned integer none (0 to 65535)
18
Command counter reading parameter set 5
A
nalog value
read unsigned integer none (0 to 65535)
19
Command counter reading parameter set 6
A
nalog value
read unsigned integer none (0 to 65535)
20
Command counter reading parameter set 7
A
nalog value
read unsigned integer none (0 to 65535)
21 Current event (event code)
A
nalog value
read unsigned integer none
22 Year of the current event
A
nalog value
read unsigned integer none
23 Month of the current event
A
nalog value
read unsigned integer none
24 Day of the current event
A
nalog value
read unsigned integer none
25 Hour of the current event
A
nalog value
read unsigned integer none
26 Minute of the current event
A
nalog value
read unsigned integer none
27 Second of the current event
A
nalog value
read unsigned integer none
28 Hundredth of a second of the current
event
A
nalog value
read unsigned integer none
* read = read data from SYNCHROTACT 5
** signed integer = whole numbers
*** unsigned integer = positive whole numbers
