ABB SYNCHROTACT 5 User Manual

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 122
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
10.5 Environmental values
10.5.1 Isolation
Dielectric test IEC 60255-5 2 kV
Impulse voltage withstand test IEC 60255-5 5 kV
10.5.2 Climatic stability
Temperature ranges for devices without communication:
Transport/storage -40 to +85 °C
Functionable -25 to +70 °C
Operation (compliance with technical data) -10 to +55 °C
Temperature ranges for devices with communication:
Transport/storage -10 to +85 °C
Functionable +5 to +70 °C
Operation (compliance with technical data) +5 to +55 °C
Tests:
Cold IEC 60068-2-1 -25 °C
Dry heat IEC 60068-2-2 +70 °C; 16 h
Damp heat, steady state IEC 60068-2-3 Ca 4 days
Damp heat, cyclic IEC 60068-2-30 55 °C/2 cycles
Change of temperature IEC 60068-2-14 Nb; 1°C/min.
10.5.3 Mechanical stability
Vibration
Vibration response
Endurance
IEC 60255-21-1 10 to 150 Hz; Cl. 2
1 g
2 g
Shocks and bumps
Shock response
Withstand
Bump
IEC 60255-21-2 class 2
10 g
30 g
20 g
Earthquake
Single-axis sine sweep seismic test IEC 60255-21-3
IEEE STD 344-1987
Method A
5g in each axis
10.5.4 Interference immunity/transmission (EMC)
Emission AC mains
(conducted disturbance)
CISPR 22 Class B
0.15..0,5 MHz: 66..56 dB/56..46 dB
0.5..5 MHz: 56 dB / 46 dB
5..30 MHz: 60 dB / 50 dB
Emission enclosure
(radiation disturbance)
CISPR 11 Class A
30..230 MHz: 30 dB
230..1000MHz: 37 dB
Electrostatic discharges IEC 60255-22-2
IEC 61000-4-2
IEEE C37.90.3-2001
Class IV
Contact: 8 kV
Air: 15 kV
