ABB SYNCHROTACT 5 User Manual

Operating Instructions SYN 5201/SYN 5202
Document No Art Part Language Revision page
abb
ABB Switzerland Ltd
3BHS109762 E01
en D 124
Template: CHIND Techn doc stand, A4 P de, R1.DOT; Filename: 3BHS109762E01 D.doc; Print: 12/6/2011 5:48:00 PM; Save: 12/1/2011 2:37:00 PM; CHIND No. 3BHS109763 ZAB D14 Rev. -; I-Q
1 MHz burst disturbance IEC 60255-22-1
IEEE C37.90.1-2002
(oscillatory)
Class III
2.5 kV common & transverse
2.5 kV common & transverse
10.6 Relevant standards
CE conformity
EMC directive:
Generic standard
Low voltage directive:
Safety of information technology
equipment
89/336/EEC
IEC 61000-6-4
IEC 61000-6-2
73/23/EEC
EN 60950
Emission
Immunity
Product standards
Measuring relays and protection
equipment
Product standard for measuring re-
lays and protection equipment
Hydro Québéc standard for electro-
nic equipment and relays
IEEE-standard for Relays
IEC 60255-6
EN 50263
SN-62.1008d
IEEE C37.90-1989
10.7 Construction data
Protection type according to IEC 60529
Front IP 54
Rear IP 50
Weight
SYN 5201/SYN 5202 4 kg
Installation altitude
<2000 m above sea level
10.8 Flammability
Front panel UL94HB
Connector housing, printed circuit boards UL94V-0
