2.8 Control options
With the SYNCHROTACT 5, a distinction is made between service control and
operating control:
Service control for commissioning and maintenance:
1. Controls on the unit: keypad & LCD (standard)
2. Local control using PC (SynView): direct link SYNCHROTACT to PC
3. Remote control through PC over the network either via SynView interface (Standard)
or over IEC 61850-interface (Option).
Operating control for normal synchronizing operation:
1. Conventional, using wired-up digital control circuits (standard)
2. Remote control using PC: via network and optional interface (Modbus, Profibus, Lon,
or IEC 61850)
