4.1.2 Event logger
The events are displayed in the following format (for meaning, see also section 9):
Line number Timestamp Event code
000
001
.
.
.
255
hh:mm:ss
. . .
. . .
. . .
. . .
. . .
Cyyy
.
.
.
.
.
4.1.3 Actual values
The following table shows the actual values and their position in the menu:
Actual values
No. Actual value name Symbol Range/resolution Unit
1. Voltage difference

U
0.0 to 99.9 %
2. Phase-angle difference


-179 to +180 DEG
3. Slip s 0.00 to 50.00 %
4. Voltage U1 U1 0 to 130*Un %
5. Voltage U2 U2 0 to 130*Un %
6. Frequency f1 f1 10.0 to 100.0 Hz
7. Frequency f2 f2 10.0 to 100.0 Hz
8. Acceleration ds/dt 0.00 to 9.99 %/s
9. Selected parameter set Pset selected 1 to 7 -
10. Software version xxxx - -
11. Command counter parameter set 1 CLOSE 1 0 to 65535 1
12. Command counter parameter set 2 CLOSE 2 0 to 65535 1
13. Command counter parameter set 3 CLOSE 3 0 to 65535 1
14. Command counter parameter set 4 CLOSE 4 0 to 65535 1
15. Command counter parameter set 5 CLOSE 5 0 to 65535 1
16. Command counter parameter set 6 CLOSE 6 0 to 65535 1
17. Command counter parameter set 7 CLOSE 7 0 to 65535 1
4.1.4 Parameter sets 1 to 7
1 parameter set is provided in the basic version, with 7 parameter sets available as an
option. The structure is the same in all parameter sets. The 7th parameter set only
differs from the others in the setting values, in that the default settings are pre-set for
synchrocheck operation.
In addition, each parameter is divided into seven functional parameter groups:
1. Actual value calibration
2. Command generation
3. Paralleling conditions
4. Dead bus conditions
5. Voltage matcher
6. Frequency matcher
7. General parameters
Each group contains the parameters associated with this function.
