ABB TPL73-A30 - Page 147

Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
Spare parts
12
View of turbocharger with part numbers
12.2
Page 145
© Copyright 2016 ABB. All rights reserved.
December 2016 HZTL2481_EN Revision B
Part number
Description
10900 Cartridge group
42012 (in customer spare part set)
O-ring
42124 (in customer spare part set) O-ring (option with compressor wheel
cooling)
51001
Gas inlet casing
56001 Nozzle ring
61001
Gas outlet casing
61036 Stud
61043 (in customer spare part set)
Verbus Ripp® Washer
61044 (in customer spare part set) Hexagon-head screw
61050 (if provided)
Gasket
61056 (in customer spare part set) Hexagon-head screw
61057 (in customer spare part set)
Verbus Ripp® Washer
61058 (in customer spare part set) Verbus Ripp® Washer
61059 (in customer spare part set)
Hexagon-head screw
61037 (in customer spare part set) Hexagon nut
61976
1)
(if present)
Centering bolt
61077
1)
(if present) Hexagon nut
63000
Turbine diffuser
68000 Foot
74018
Washer
74026 / 74029 Stud
74027
Hexagon nut
74000 Compressor casing external part
76000
Compressor casing internal part
76040 (in customer spare part set) O-ring
76080
Safety segment
77000 Wall insert
77005 (in customer spare part set)
O-ring
77006 (in customer spare part set) O-ring
79000
Diffuser
81000 Filter silencer
82000
Radial air suction branch
82000 Axial air suction branch
1)
TPL69-A only
