Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
Disassembly and assembly
8
Dismantling and installing the turbine
diffuser and nozzle ring
8.6
Page 101
© Copyright 2016 ABB. All rights reserved.
December 2016 HZTL2481_EN Revision B
Dismantling and installing the turbine diffuser
and nozzle ring
8.6
CAUTION
Falling nozzle ring
The nozzle ring hangs only loosely on the positioning pins.
 Before removing the turbine diffuser, secure the nozzle to prevent it
from falling.

Before disassembling the turbine diffuser, if possible secure the nozzle
ring against falling with a lashing strap and a wooden block.
