Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
Warning plates on the turbocharger
Page 19
© Copyright 2016 ABB. All rights reserved.
December 2016 HZTL2481_EN Revision B
Warning plates on the turbocharger
2.5
Warnings that have been attached to turbochargers by ABB Turbo Sys-
tems must not be removed. Illegible warnings must be replaced with new
ones. Further information is available from ABB Turbocharging service
stations.
81080 105 x 74 TPL / TPR
When uninsulated turbochargers are delivered to the engine builder, the
warning plates must be subsequently attached to the insulation. This is
the responsibility of the engine builder.
