Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
Start
-up
3
Oil supply
3.1
Page 31
© Copyright 2016 ABB. All rights reserved.
December 2016 HZTL2481_EN Revision B
Oil temperature
Lubricating oil temperature at the inlet
CAUTION
Machine damage
If the oil temperature at the oil inlet exceeds the admissible range, this
may lead to engine damage.
 Observe oil temperature at the oil inlet according to the following table.
Status for operation
Oil temperature at the inlet
T
oil,inlet
[°C]
TPL69-A10/30
TPL73-A10/30
TPL77-A10/30
Permissible 30 … 95 30 … 80
Temporarily permissible (< 1h) -> alarm
> 95
> 80
Not permissible -> stop the engine > 100 > 85
Not permissible -> Do not start the engine
(before starting: preheat the oil)
< 30
< 30
Lubricating oil temperature at the outlet
The oil temperature at the outlet is mainly dependant on:
 Lubricating oil temperature and pressure at the oil inlet
 Engine load and turbocharger speed
 Exhaust gas temperature
The maximum admissible oil temperature at the outlet is listed in the fol-
lowing table. The specified oil outlet temperature is to be considered as
alarm value for the turbocharger operation and must be monitored accord-
ing to the current regulations.
Status for operation
Oil temperature at the outlet
T
oil,outlet
[°C]
TPL69-A10/A30
TPL73-A10/30
TPL77-A10/30
Permissible ≤ 145 ≤ 130
Temporarily permissible -> alarm > 145 > 130
Not permissible -> stop the engine > 165 > 150
If the turbocharger was operated for a longer period of time outside of the
admissible range, ABB Turbo Systems recommends to have the turbo-
charger inspected by an ABB Turbocharging Service Station.
