ABB TPL73-A30 - Page 92

Operation Manual / TPL69-A10 / -A30 ... TPL77-A10 / -A30
Disassembly and assembly
8
Module weights
8.2
Page 90
© Copyright 2016 ABB.
All rights reserved.
December 2016 HZTL2481_EN Revision B
Complete compressor casing internal part
TPL69-A
TPL73-A
TPL77-A
210 350 620
NOTICE
The total weight of the complete internal part of the compressor casing
includes the internal part of the compressor casing, the diffuser and the
wall insert.
Weights [kg]
