ABB TRIO-5.8-TL-OUTD-S

- 23 -
000318CG
2 - Characteristics
Bracket dimensions
The wall mounting bracket dimensions are expressed in mm and inches
334mm / 13.15”
52.4mm/2.06”
58mm/2.28”
27mm
1.06”
10mm
0.39”
10mm
0.39”
18mm
0.70”
18mm
0.70”
230mm/9.05”
115mm/4.52”
115mm/4.52”
18mm/0.70”
6mm/0.23”
44mm/1.73”
6.5mm/0.25”(2X)
25mm
0.98”
19mm
0.74”
62mm/2.44”
(4X)
334mm / 13.15”
