ABB TRIO-5.8-TL-OUTD-S

- 33 -
000321CG
2 - Characteristics
IN1
+
-
MPPT 1
(DC/DC)
*IN2
+
-
MPPT 2
(DC/DC)
Bulk caps
Inverter
(DC/AC)
Line
filter
DC/DC
DSP
contr.
DC/AC
DSP
contr.
Control circuit
Grid parallel
relay
L1 L2 L3
N
PE
IN1.1(-)
IN1 IN2 +
- + -
*IN2.1(-)
Standard version
IN1 IN2
+
-
+
-
-S version
IN1.1(+) IN1.2(+) IN1.1(-) IN1.2(-) *IN2.1(+) *IN2.2(+) *IN2.1(-) *IN2.2(-)
IN1.1(+) *IN2.1(+)
µP
Supervisor
board
Service pc_RS485
+ T/R
- T/R
GND
Remote control 1
+ R
GND
Alarm
N.C N.O C
Remote control 2
+ R
GND
PMU analog input
I1 I2
GND
analog input
AN2
AN2 COM
24V-100mA
24V
GND
Termal sensor PT100/PT1000
PT1 PT2
PT3
analog input
AN1
AN1 COM
PMU digital input
K1 K3
K4
MODBUS/PMU RS485
+ T/R
- T/R
GND
K2
Service
board
(opt.)
(*) Not available in TRIO-5.8-TL-OUTD versions
Ethernet
board
(opt.)
RJ_45
